Submersible dirty water pump with crusher Pedrollo TIGm 0.75kW, single phase

Code: 10010

Guarantee: 24

753 € / 1,472.74lv.

OPERATING CHARACTERISTICS:

Flow Rate: up to 140 l/min (8.4 m³/h)
Head: up to 18.5 m

DESCRIPTION:

The TRITUS INOX submersible electric pumps are reliable, safe, and resistant to clogging. The grinding unit with its displacement cutting system drastically reduces the engine's torque requirements. It thoroughly grinds waste while using less energy and eliminates blockages caused by problematic items such as plastic, rubber, fabrics, feminine hygiene products, wet wipes, protective masks, latex gloves, and other sanitary products.

These pumps with cutting mechanisms are particularly recommended when it is necessary to transport waste water over long distances or through compact-sized pipes. They are suitable for installations that are not appropriate for gravity systems or are located in areas not served by sewer systems.

APPLICATIONS:

TRITUS INOX is recommended for:

Toilet systems
Slaughterhouse waste
Food and beverage industry
Paper mills
Farms
Other industrial activities

HYDRAULIC CHARACTERISTICS:

Flow Rate (m³/h)	0	1.2	2.4	3.6	4.8	6	7.2	7.8	8.4
Liters/Min	0	20	40	60	80	100	120	130	140
Head (m)	18.5	17.5	16.1	14.6	12.8	10.8	8.4	7	2

Characteristic	Value
Maximum Head	18.5 m
Maximum Flow Rate	140 l/min (8.4 m³/h)
Discharge Connection	G 1½"
Maximum Immersion Depth Below Water Level	5 m
Motor Type	Single-phase 230 V - 50 Hz
Power (P2)	0.75 kW (1 HP)
Rotation Speed (RPM)	2900
Insulation Class	F
Protection Degree	IP X8
Maximum Number of Starts per Hour at Equal Intervals	20
Minimum Immersion Depth for Continuous Operation	250 mm
Starting Capacitor (for single-phase pumps only)	Built-in
Pump Casing	Cast iron
Impeller	Open type, technopolymer
Cable Length	10 m
Construction Features	Double mechanical seal in oil chamber
Built-in Float	Yes
Liquid Type	Drainage and sewage water
Maximum Liquid Temperature	+40°C
Suction Height from Bottom	85 mm
