Vertical multistage pump Pedrollo HT 8/4 three-phase

Code: 10008

Guarantee: 24

1144 € / 2,237.47lv.

OPERATING CHARACTERISTICS:

Flow Rate: up to 200 l/min (12 m³/h)
Head: up to 58 m

Q (m³/h)	0	1.2	2.4	3.6	4.8	6.0	7.2	8.4	9.6	10.8	12.0
l/min	0	20	40	60	80	100	120	140	160	180	200
H (m)	58	58	55	52.5	49.5	45.5	41	35.5	30	23.9	18

CONSTRUCTIVE CHARACTERISTICS:

Body: Cast iron JL250
Diffusers: Stainless steel AISI 304
Impellers: Stainless steel AISI 304
Diaphragms: Stainless steel AISI 304
Shaft: Stainless steel AISI 431
Mechanical Seal: GRAPHITE - CERAMIC – NBR

The pumps are suitable for water supply, transfer of clean liquids, and pressure boosting in civil, industrial, and agricultural installations. The multi-stage design ensures very low noise levels during operation. The electric motor with a new design, designed for use with inverters, provides balanced and quiet operation. Efficiency class IE3, insulation class F, and protection IPX4.

Characteristic	Description
Maximum Head:	58 m
Maximum Flow Rate:	200 l/min (12.0 m³/h)
Inlet Connection:	G 1½"
Outlet Connection:	G 1½"
Maximum Suction Depth:	7 m
Motor Type:	Three-phase 230/400 V - 50 Hz
Power (P2):	1.5 kW (2 HP)
Rotation Speed (RPM):	2900
Insulation Class:	F
Protection Rating:	IP X4
Type:	Vertical multi-stage
Pump Body:	Cast iron
Impeller:	AISI 304
Usage:	Agricultural; Industrial; Public
Liquid Type:	Clean water
Minimum Liquid Temperature:	-15°C
Maximum Liquid Temperature:	+90°C
Maximum Ambient Temperature:	+40°C
Maximum Working Pressure:	16 bar
